Product features
Side wall or curtain wall automatic exhaust system is a kind of elegant high level professional exhaust system with automatic control functions of automatic exhaust system, as a professional design by the automatic fire smoke exhaust and smoke exhaust device of automatic alarm linkage control device, it includes forms, actuators, self-locking mechanism and automatic control system. The system design fully embodies the most economical optimization solution in ensuring the beauty and fire protection requirements, curtain wall structure and mechanical performance requirements.
Using range
When the smoke or hot air is naturally floating in the fire, the building is excluded by the automatic smoke exhaust system installed on the side wall of the building.
Technical performance index
Main source: 220V/50HZ 380V/50HZ.
Power supply: DC24V 10%.
size
The size of the smoke window of the side curtain wall is consistent with that of "building doors and Windows opening size series" (gb5824-86).
The maximum size of the smoke window of the side curtain wall is X height (1800mmX1500mm)
Design selection
The automatic smoke exhaust window form material is high quality aluminum alloy profile, surface electrostatic powder coating or fluorocarbon baking varnish treatment, glass is commonly used 5+6A+5 toughened hollow safety glass.
Common hole size and main technical parameters are shown in the following table:
The installation position of the control box and the button box should be considered when using this exhaust window, so as to avoid the installation and effective control.
The power supply and signal line shall be provided by the electrical installation to a distance of 1000mm from the electric control box.
Schematic diagram
